| Brand Name : | DX |
| Model Number : | DX |
| Certification : | ROHS/ISO9001:2008 |
| Price : | FOBShanghai USD |
| Delivery Time : | 15 Days after receiving your payment |
| Payment Terms : | T/T,L/C |
| Supply Ability : | 3000000pcs per month |
contact with us: yxl(at)duoxin(dot)com
1 SOUND PRESSURE LEVEL
85±3dB SPL（Average at 800Hz,1000Hz,1200Hz,1500Hz）
Measuring condition: 0.1W (Sine wave) 0.1m measured with baffler shown in Fig.1.
2 IMPEDANCE: 8±20%Ω(@2KHz 1V) without baffle
3 RATED POWER: 1.0W（White Noise for 48hours）.
MAX POWER: 2.0W.
4 RESONANCE FREQUENCY (F0): 650±20%Hz @ 1V.
5 SOUND POWER: 1.0W (F0~6KHz) must be normal with sine wave (2.8Vrms).
|
